public class JDRoundRectangle extends JDRectangular
Here is an example of few JDRoundRectangle:
FILL_STYLE_DOT_PATTERN_1, FILL_STYLE_DOT_PATTERN_2, FILL_STYLE_DOT_PATTERN_3, FILL_STYLE_GRADIENT, FILL_STYLE_LARGE_CROSS_HATCH, FILL_STYLE_LARGE_LEFT_HATCH, FILL_STYLE_LARGE_RIGHT_HATCH, FILL_STYLE_NONE, FILL_STYLE_SMALL_CROSS_HATCH, FILL_STYLE_SMALL_LEFT_HATCH, FILL_STYLE_SMALL_RIGHT_HATCH, FILL_STYLE_SOLID, LINE_STYLE_DASH, LINE_STYLE_DASH_DOT, LINE_STYLE_DOT, LINE_STYLE_LONG_DASH, LINE_STYLE_SOLID, VALUE_CHANGE_ON_XDRAG_LEFT, VALUE_CHANGE_ON_XDRAG_RIGHT, VALUE_CHANGE_ON_YDRAG_BOTTOM, VALUE_CHANGE_ON_YDRAG_TOP, VALUE_INC_ON_CLICK, VALUE_INC_ON_PRESSRELEASE
Constructor and Description |
---|
JDRoundRectangle(java.lang.String objectName,
int x,
int y,
int w,
int h)
Contructs a JDRoundRectangle.
|
Modifier and Type | Method and Description |
---|---|
JDPolyline |
convertToPolyline()
Convert this object to a JDPolyline
|
JDObject |
copy(int x,
int y)
Returns a copy of this object at the specified location.
|
int |
getCornerWidth()
Returns the rouded corner width.
|
int |
getStep()
Returns the interpolation of rounded corner.
|
boolean |
isInsideObject(int x,
int y)
Determines whether the specified point is inside this object.
|
void |
setCornerWidth(int w)
Sets the rounded corner width.
|
void |
setStep(int s)
Sets the interpolation step of the rounded corner.
|
moveSummit, paint, rotate90
addExtension, addMouseListener, addValueListener, centerOrigin, clearMouseListener, clearValueListener, getBackground, getBackgroundMapper, getBoundRect, getExtendedParam, getExtendedParam, getExtendedParamDesc, getExtendedParamIndex, getExtendedParamName, getExtendedParamNumber, getFillStyle, getForeground, getForegroundMapper, getHTranslationMapper, getInitValue, getInvertShadowMapper, getLineStyle, getLineWidth, getMaxValue, getMinValue, getName, getObjectsByName, getOrigin, getShadowWidth, getSummit, getSummitNumber, getValue, getValueChangeMode, getVisibilityMapper, getVTranslationMapper, hasBackgroundMapper, hasExtendedParam, hasForegroundMapper, hasHTranslationMapper, hasInverseShadow, hasInvertShadowMapper, hasShadow, hasVisibilityMapper, hasVTranslationMapper, isAntiAliased, isDisabled, isFixedExtendedParam, isInteractive, isProgrammed, isVisible, moveSummitH, moveSummitV, preRefresh, refresh, removeExtension, removeMouseListener, removeValueListener, restoreTransform, saveTransform, scale, scaleTranslate, setAntiAlias, setBackground, setBackgroundMapper, setDisabled, setExtendedParam, setExtendedParam, setExtensionList, setFillStyle, setForeground, setForegroundMapper, setGradientFillParam, setHTranslationMapper, setInitValue, setInteractive, setInverseShadow, setInvertShadowMapper, setLineStyle, setLineWidth, setMaxValue, setMinValue, setName, setOrigin, setShadow, setShadowWidth, setValue, setValueChangeMode, setVisibilityMapper, setVisible, setVTranslationMapper, toString, translate
public JDRoundRectangle(java.lang.String objectName, int x, int y, int w, int h)
objectName
- Object namex
- Up left corner x coordinatey
- Up left corner y coordinatew
- Rectangle widthh
- Rectangle heightpublic JDObject copy(int x, int y)
JDObject
public boolean isInsideObject(int x, int y)
JDObject
isInsideObject
in class JDObject
x
- X coordinate (pixel)y
- Y coordinate (pixel)public JDPolyline convertToPolyline()
public int getStep()
setStep(int)
public void setStep(int s)
s
- Interpolation steppublic int getCornerWidth()
setCornerWidth(int)
public void setCornerWidth(int w)
w
- Corner width
