overview non-standard sample environment
non-standard setups. Please contact beam-line personnel if you are interested in using any non-standard setup | |||
high magnetic field |
Up to 7 T 30 T pulsed |
||
The XMaS/AMI superconducting magnet
transverse or longitudinal fields can be applied
|
4T 40mm warm bore 180º scattering aperture |
||
polymer processing |
Reference: E.M. Troisi et.al. “Structure evolution during film blowing: An experimental study using in-situ small angle X-ray scattering”, Eur. Polymer Journal, Volume 74, (2016) 190-208; doi:10.1016/j.eurpolymj.2015.11.022 |
||
in-situ film stretching | |||
shear | Anton Paar extensional rheometer | simultaneous furnace and couette cell | |
vertical orientation shear cell | |||
MPR Eindhoven shear cell | with simultaneous SAXS and WAXS | ||
microfluidics | |||
high pressure sample cell for reactions in supercritical fluids (e.g. supercritical CO2) Reference: Daniel Hermida-Merino, Giuseppe Portale, Peter Fields, Richard Wilson, Simon P. Bassett, James Jennings, Martin Dellar, Cedric Gommes, Steven M. Howdle, Benno C. M. Vrolijk, and Wim Bras; “A high pressure cell for supercritical CO2 on-line chemical reactions studied with x-ray techniques”; Review of Scientific Instruments, 85, 093905 (2014), DOI: http://dx.doi.org/10.1063/1.4895717
|
pressures up to 210 bars and temperatures up to 120 °C |
