The experimental hutch starts just after the safety beam shutter located in the optic hutch. In this hutch, users carry out experiments.

The MAD beamline has been designed in only one experimental hutch : EH3. Unlike most of beamlines, EH3 is located far from the last optical hutch. Indeed 31.170m separate the two hutches OH3 and EH3.



Under Construction




Experimental Elements Description
Experimental table A solid block of granit to support the experimental devices
Toroidal mirror




See here an overview of EH3 with dimensions.
